The 10GBASE-T Copper SFP Transceiver is small form factor pluggable transceiver. They are compatible with SFP Multi- Sourcing Agreement (MSA) and comply with Gigabit Ethernet standard as specified in IEEE Std 802.3. They are compliant with RoHS and lead-free per Directive 2002/95/EC. The physical layer IC (PHY) can be accessed via I2C bus, allowing access to all PHY settings and features.
More Details(DS070015)
|
Part No. |
Data Rate |
Distance*Note1 |
Interface |
Bail color |
Temp. *Note2 |
DDMI |
|
TCS-TGD0-01DCR |
10G |
30m |
RJ45 |
NA |
ST |
Y |
|
TCS-TGD0-01DIR |
10G |
30m |
RJ45 |
NA |
IT |
Y |
Features:
-
Operating data rate up to 10G
- Compact RJ-45 connector assembly
- Single 3.3V power supply and Low power dissipation
- Hot Pluggable
- 10GBASE-T operation in the host systems with SGMII interface
- RoHS Compliant and Lead-Free
- Metal with lower EMI and excellent ESD performance
- Commercial operating temperature range: 0°C to +70°C , -40 °C ~ to 85°C
Applications:
-
10GBASE-T IEEE802.3an
- 1000BASE-T IEEE802.3ab
- 100BASE-TX IEEE802.3u
- 5G MGBASE-T
- 2.5G MGBASE-T
